OCAM Deluxe Steel Bull Bar For Isuzu D-MAX 08/2020-04/2024, Winch Compatible

OCAM Deluxe Steel Bull Bar For Isuzu D-MAX 08/2020-04/2024, Winch Compatible

OEM QUALITY STANDARD!

SKU: BB2-DMAX-21-P

group_id: 1
RRP $1,995.00

$1,695.00

FREQUENTLY BOUGHT WITH

Colour Paint Matching for Bull Bars. Plse confirm your colour code

$795.00

Description

OCAM Bull Bar For Isuzu D-MAX 08/2020-04/2024, Heavy Duty Steel ADR Compliant


Does not suit the 2024 facelift model


WARRANTY - 2 YEARS

COMBO SPECIALS AVAILABLE. Choose your preference using the dropdown menu.


Are you looking to install a full-protection bull bar on your 4WD?  If so, good decision!!

With over 50 million kangaroos roaming across Australia (est. 2022), the reason is now bigger than ever. Installing a full protection bull bar to your 4WD not only makes your vehicle off-road capable, but it also makes driving so much safer, especially in country and rural areas.

In the event of an animal road strike, a bull bar offers vital protection. It means that most likely you'll be able to continue driving your 4WD after impact, because the vital components such as the radiator for your vehicle to operate, are protected from severe damage. Otherwise, you'll most likely be stranded, and in need of a tow.

A bull bar is also a rigid structure for mounting essential offroad accessories such as a winch, driving lights, and UHF antenna.

The OCAM Deluxe Bull Bar is a premium product. It is designed to match the vehicle's shape and lines so that it fits and protects perfectly and enhances the vehicle's appearance.



MANUFACTURING

The OCAM bull bars are manufactured overseas using quality materials and processes. Our appointed manufacturer is a fully-approved OEM facility, which produces a wide range of vehicle accessories for the global automotive market, including various major vehicle manufacturers. All aspects of the manufacturing process are quality controlled and maintained.



CRASH TESTING / ADR COMPLIANCE

The OCAM bull bars are crash tested in Australia and ADR compliant. The energy-absorbing system is a patent-pending design and is among the market-leading solutions. Our investment in crash testing and certifying our bull bars means you can rely on the OCAM bull bar for frontal protection to get you anywhere and home safely.



RECOVERY POINTS

The OCAM bull bars come with integrated factory recovery points which are rated to 3400kgs when used together with an equaliser strap. This extra benefit not only saves you on cost but also means there is no need to go out looking for recovery points to suit.



POWDER-COATING

In finishing, the OCAM bull bars go through a rigorous 4-stage powder coat process. It involves:

  1. Pre-treatment: The bull bar raw metal is cleaned and rinsed to remove all impurities. Any trace of material oil and rust is removed. It is then phosphatized, which is a metalworking process involving the use of phosphoric acid to create a protective layer over the metal.
  2. Cathodic epoxy electrocoating: This is the global benchmark for corrosion resistance and provides the bull bar with superior adhesion and corrosion protection. It covers every corner of the product.
  3. Prime Powder Coat: Fixes any imperfections on the surface, e.g., scratch marks, etc., and provides corrosion protection reinforcement for a long-lasting finish.
  4. Top powder coat: Completes the bull bar with a layer of Corrosion Protection ultra-reinforcement and an excellent smooth surface finish.



HOW STRONG ARE OCAM 4X4 BULL BARS?

With strength and reliability in mind, we’ve implemented a few design features to ensure you can have peace of mind when traveling throughout Australia. The bar uses a 63mm top tube and is 100% welded top and bottom through the 2.5mm plate bar. Reinforcement plates are used on the underside unlike many others to guarantee additional strength!




DELUXE VALUE

All OCAM Bull Bars are equipped with LED turn signals, parking, and daytime running lights for OEM replacement. The fog lights are LED and are included at no additional cost! They come with 3 x top tube mounts for all your additional accessories and 2 x high lift jack points. All OCAM bull bars are winch compatible and come with the number plate flip mount.




FEATURES:

  • Modern and market-leading energy absorber system (Patent-Pending)
  • Winch compatible - perfect for off-road use
  • Heavy-duty steel construction for optimum strength
  • The latest design in LED's; fog lights with dual brightness options, parkers and modern indicators
  • SRS airbag tested and certified in Australia (ADR approved)
  • High-grade black e-powder coat for long-lasting protection against rust and ultimate-look finish
  • Underbody skid-protection plates
  • Polyurethane protection bumpers
  • 63mm top tube, with aerial / lighting mounting brackets
  • 2 x high lift jack points
  • 2 x recovery points, rated to 1700 kgs each. Total 3400 kgs using equaliser strap
  • Number-plate swivel bracket
  • Complete mounting kit with instructions.

Notes

  • Will not suit the X-Terrain model



FITTING

We offer a complete fitting service at all OCAM locations. Our dealer network across Australia is growing and we now offer a fitting service in various regions too. If you'd like a quote to include fitting, please be in touch. Just let us know your postcode, suburb, and which accessories you'd like fitted up. We'll confirm pricing for you asap.

* If you're based in an area where we don't have a fitting arrangement in place as yet, we welcome working with you to locate a suitable fitter.

Download fitting instructions



2 December 2019
"Josh here, picked up the bullbar from you guys couple of days ago just finished the install went smoothly and looks great I've attached some photos cheers guys."

Josh D. VIC.


11 October 2019
"Great product and service - Purchased the bar at Sunshine Coast Expo and dealt with Daniel. He was great to deal with and very informative. Picked it up same day and fitted that weekend, was very straight forward to fit the bar and couldn’t be happier with the end result. Would recommend to anyone looking for premium gear without the premium price.
Caleb C. QLD.



27 April 2019
"I bought my Amarok straight out of VW and I approached OCAM to fit my Bull Bar and wow what a difference it has made. The guys at OCAM gave me great service and did a professional job which is why I went there in the first place. Friendly reliable service and as a result I will be dealing with OCAM for further after market enhancements to my vehicle!"
Ekrem F. VIC




PICK UP & PHONE ENQUIRIES WELCOME


Specifications



CONSTRUCTION:

Material Steel
Bar thickness 2.5mm
Tubing diameter 63mm
Tubing thickness 2mm
Tabs 3 points (Antenna or light brackets)
Underbody protection plates YES
Bumper over-riders YES
Total weight 79 Kgs

COMPATIBILITY:
OE parking sensor YES
Headlight washer  -
Winch compatible YES
High lift jacking points YES x 2
Tow-points YES - 1700kgs x 2. Total 3400kgs using equaliser strap.

LIGHTING
LED fog lights YES
LED indicator/parker lights YES

SAFETY
Airbag compatible YES

INSTALLATION
Mounting hardware YES
Instructions YES



KEY SPECIFICATIONS
SKU BB2-DMAX-21-P
Brand OCAM
Shipping Weight 79.000000kg
Shipping Width 0.600m
Shipping Height 0.900m
Shipping Length 2.000m
Shipping Cubic 1.080000000m3
PACKAGE CONTENT


Bull Bar

  • 1 x Steel bull bar
  • 1 x Winch mounting bracket
  • 2 x LED Fog lights, parkers and indicators sets
  • Complete set of underbody skid protection plates
  • 2 x Polyurethane protection bumpers
  • Full mounting & installation kit
  • Fitting instructions



Delivery & Returns
PICKUP & SHIPPING


Pick-up locations:


VICTORIA

  • 31 Shirley Way, Epping 3076
    Tel: (03) 9357-0306
  • Unit 1, 7 Tarmac Way, Pakenham 3810
    Tel: (03) 7043-1133


QUEENSLAND

  • Unit 5, 1927 Ipswich Road, Rocklea 4106
    Tel: (07) 3275-2132
  • 25 Torres Crescent, North Lakes 4509
    Tel: (07) 2112-9100
  • 2, 92 Link Crescent, Coolum Beach QLD 4573
    TelL: (07) 2142-8899


NEW SOUTH WALES

  • Unit 2, 31-33 Lyn Parade, Prestons 2170
    Tel: (02) 9136-0000


WESTERN AUSTRALIA

  • 41 Horus Bend, Bibra Lake 6163
    Tel: (08) 6385-6333


SOUTH AUSTRALIA

  • Unit 2, 28-30 Hudson Road, Mawson Lakes 5095
    Tel: (08) 7082-2844


All items are shipped within 24 hours of payment receipt, except; on weekends, as mutually agreed, during high-volume periods such as holiday and promotion periods, or as may be otherwise stated.

Free pick-up (click and collect) is available from all locations listed above. Please contact us to confirm stock is available prior to your arrival. You will need to present a government-issued I.D., for all prepaid pick-ups.

Should you choose free pick-up and your item is not in stock at your chosen location, a free stock transfer is available (excluding trays & canopies). Stock transfers occur on a fortnightly basis and will require additional handling time.

For shipping orders, we aim to keep your cost as low as possible. The shipping rates on our website are calculated from the warehouse nearest to you to ensure you get the best deal. If your item isn't available nearby, we might need a little extra time to handle your order. Also, items can be combined to reduce shipping costs.

Some remote areas will incur additional shipping charges. These include, but are not limited to; N.T., Far North QLD, and remote W.A. If you live in a remote area, please contact us to confirm whether additional shipping charges will apply to your order.



Should you require any additional information, click here to email our customer service team, or phone your nearest OCAM 4x4 Accessories store.



RETURN & WARRANTY



WARRANTY

For your total confidence, OCAM offers a 1-year warranty on this product. We place a high value on customer service and aim to ensure you are completely satisfied with your purchase. If you require any assistance with your product, please contact us.



RETURNS



CHANGED YOUR MIND?

No problem! You may return or exchange any product within 30 days, as long as the item is in resalable condition and is returned in its original packaging. You will be responsible for the original and return shipping charges and a restocking fee of 10%. This also applies to orders cancelled during transit. If your original purchase price includes shipping, please contact us to confirm the original shipping cost. A refund, credit or replacement will be issued after we have received the package and confirm the item is in a resalable condition. Returns will not be accepted if you contact us after 30 days of receiving the item.




FAULTY OR INCORRECT ITEM?

The item needs to be returned and will be replaced or a full refund or credit provided. Please contact us ASAP if you would like to make a claim.




WHAT CAN BE RETURNED?

All our products are returnable.




WHEN DO ITEMS NEED TO BE RETURNED BY?

Within 30 days of receipt. Returns will not be accepted if you contact us after 30 days of receiving the item.




HOW TO RETURN ITEMS?

By post, courier or visit personally.





WHERE TO RETURN ITEMS?

To your nearest OCAM 4x4 Accessories store.




PACKAGING MATERIALS?

Items need to be returned in original packaging.




ADDITIONAL NOTES

If the product is damaged during installation or due to a lack of ongoing maintenance, we are not responsible and will not issue a refund or credit.

When you have received your package, please inspect your product for any manufacturer defects or shipping damage prior to installation. If you notice any damages or defects, please contact us ASAP.

Before any returns or exchanges, please contact our customer service representatives via email at hello@ocam.com.au. Please include your order number and specific description of damage/problem, photos and a clear explanation of your reason. If the return is authorised, you will receive an email with return instructions. All emails will be replied to within 24 business hours.



Reviews
(5)
Great Bar at a great price
By: brianrlam184000 on 19 October 2022
Had the Ocam Bar fitted to my new Isuzu Ute….great solid looking bar fitted winch at the same time. Very happy Chappy!!!
